Ceramic fiber module of Jahan Ayegh Pars Company has excellent refractory, energy saving and insulating effects, and it has low heat storage. Ceramic fiber module can be directly fixed on the shell of the industrial furnace. Ceramic fiber module improves the refractory and insulating integrity of furnaces and improves furnace construction process. Ceramic fiber modules of Jahan Ayegh Pars Company are made from high-quality spun fiber blanket, and then folded and compressed to standard dimensions. Modules are dense blocks of high temperature fiber insulation.
These modules are specially designed to meet or improve the thermal insulation requirements of industrial furnaces in some special thermal conditions.

Applications:

 Boiler, anneal furnace, ceramic furnace insulation
 Ethylene & reformer furnace roof and walls
 Refining and petrochemical

Features:

 Fast and easy installation
 Lower heat storage and fuel costs
Low insulation costs

• Pictures
• Technical Data

• Pictures
• Technical Data

Pictures

Technical Data

Properties	Unit	Type A Module	Type B Module	Type C Module
Classification Temperature	C°	1260	1260	1430
Continues Use Temperature	C°	1100	1200	1350
Density	Kg/m3	220	220	220
Thermal Conductivity (w/m.k)	204 C°	0.088	0.098	0.108
	427 C°	0. 114	0.116	0.142
	649 C°	0.149	0.172	0.164
Linear Shrinkage	%	≤ 2.7	≤ 2.7	≤ 3.7
